ZwickRoell 웨비나 녹화 동영상 시청 링크

여기에서 ZwickRoell 웨비나 녹화 동영상을 확인할 수 있습니다. 궁금한 사항은 webinar@zwickroell.com으로 문의해 주세요.

고온 시험 자동차 금속 의료 플라스틱 복합재료 일반 정보 testXpert III 시험 소프트웨어

고온 시험을 위한 가상 시험 포럼

자동차

Reliable mechanical characterization of Lithium Ion Battery components
Lithium-ion batteries are the backbone of current electric mobility. The industry is developing new technologies at an urgent pace, and ZwickRoell testing solutions for mechanical characteristic values support the efforts in making battery cells more efficient, sustainable, more powerful, lighter, and safer.
다운로드 위치 Reliable mechanical characterization of Lithium Ion Battery components
Mechanical testing solutions for hydrogen fuel cell components
Fuel cells are becoming an increasingly important part of sustainable drive technology in the automotive industry. Different mechanical tests on fuel cell components such as MEA (membrane electrode assemblies), CCM (catalyst coated membrane) and GDL (gas diffusion layer), individual cells, or complete stacks are performed in the areas of research and development, production, and quality assurance.
다운로드 위치 Mechanical testing solutions for hydrogen fuel cell components
Multi-Axis Transducer Calibration for Automotive Applications
Testing technology for automotive applications is increasingly relying on multi-axial force and moment measurements. We will present multi-component measuring systems and different approaches for their calibration. We will focus on the attainable measurement uncertainty using the newly available measuring equipment, and the cost/benefit ratio.
다운로드 위치 Multi-Axis Transducer Calibration for Automotive Applications
Materials Testing in Hydrogen Technology – Challenges, Requirements, Solutions
Hydrogen, generated with renewable energy, is the promising energy storage type of the future. The challenges in the hydrogen value chain , from hydrogen generation to storage and transportation as well as end use, are numerous and especially materials used for these purposes have to be adapted to tough conditions.
다운로드 위치 Materials Testing in Hydrogen Technology – Challenges, Requirements, Solutions

금속

Testing in high-temperature to ISO 6892-2 A1 with new furnace, makroXtens HT and hot-loading
Strain-controlled high-temperature tensile tests to ISO 6892-2 A1 can now be carried out with the new flexible high-temperature furnace from ZwickRoell and with use of the proven makroXtens HT and laserXtens HP/TZ—also with optional hot loading function.
다운로드 위치 Testing in high-temperature to ISO 6892-2 A1 with new furnace, makroXtens HT and hot-loading
ASTM and ISO Metal Tension Testing under Strain Rate Control in “closed loop” and “open loop” technique
Reliable and reproducible test results require equal settings of the correct test speeds. The ASTM and ISO standards for standard tensile testing on metals were expanded in 2009 to include strain rate control. With this method, significantly more uniform test speed settings and control were achieved. This method can be implemented with almost every testing machine.
다운로드 위치 ASTM and ISO Metal Tension Testing under Strain Rate Control in “closed loop” and “open loop” technique
Save and Reliable Tension Testing of Advanced High Strength Steels
Tensile testing on materials in the AHSS (advanced high-strength steel) and UHSS (ultra-high-strength steel) categories, requires advanced testing technology that can sustain increased wear of tools and measuring technology. This particularly applies to the specimen gripping techniques, as well as strain measurement to the point of specimen failure.
다운로드 위치 Save and Reliable Tension Testing of Advanced High Strength Steels
Simply see more: 2D DIC Applications
Without the need for additional hardware, the ZwickRoell videoXtens can be expanded with a valuable function: the ZwickRoell 2D DIC. This function allows for live strain measurement with a single extensometer, followed by 2D DIC analysis.
다운로드 위치 Simply see more: 2D DIC Applications
r-value determination on metal acc. ISO & ASTM
The r-value, or more accurately the vertical anisotropy, is one of the typical characteristic values determined from tensile tests in accordance with ISO 10113, ASTM E517 or JIS Z2254. Up until 2020, determination of the r-value to ISO 10113 was based solely on the assumption that a metal material showed no taper within the parallel length, in the range up to uniform extension Ag.
다운로드 위치 r-value determination on metal acc. ISO & ASTM

의료

Tests in the medical and pharmaceutical industry require a specific level of automation
Testing machines for the medical and pharmaceutical industry are used for a wide range of purposes. Areas of application, including R&D or quality assurance, are accompanied by different requirements. Depending on the number of test specimens, throughput time or the extent of necessary test steps, either manual, semi-automatic or fully automatic testing systems may be used.
다운로드 위치 Tests in the medical and pharmaceutical industry require a specific level of automation
Standard compliant tests on modern injection systems
Hypodermic syringes, pens and autoinjectors are used for the administration of medications and vaccines. The standards specify comprehensive test requirements to ensure product quality, which in turn demands testing technology that guarantees reliable results. In addition, the testing software must meet regulatory data security requirements.
다운로드 위치 Standard compliant tests on modern injection systems
Standard compliant tests on spinal implants
Different implant systems are available to treat diseases of the spine. These range from rod and screw systems to cages and vertebral body replacement devices. Numerous ISO and ASTM standards require comprehensive static and dynamic tests for product quality assurance. In this webinar you will learn about the various test standards and the corresponding ZwickRoell testing solutions.
다운로드 위치 Standard compliant tests on spinal implants
Automation and digitalization pose new challenges for testing in the medical technology and pharmaceutical industry
Testing machines for the medical and pharmaceutical industry are used for a wide range of purposes. Areas of application, including R&D or quality assurance, are accompanied by different requirements. Depending on the number of test specimens, throughput time or the extent of necessary test steps, either manual, semi-automatic or fully automatic testing systems may be used.
다운로드 위치 Automation and digitalization pose new challenges for testing in the medical technology and pharmaceutical industry

플라스틱

Reliable Melt Flow Testing with advanced instruments and new functions
Melt flow testing (ISO 1133, JIS K 7210, ASTM D1238 as a general method and ASTM D3364) is a simple way to characterize the flow properties of a plastic melted mass. This test method is widely used, especially in quality assurance and goods inwards testing. Demands on the extrusion plastometer vary according to which processing stage in the plastics industry is involved. ZwickRoell has an extrusio
다운로드 위치 Reliable Melt Flow Testing with advanced instruments and new functions
Standard-Compliant Measurement of Tensile and Flexural Properties on Plastics
This webinar will show you how to determine the tensile and flexural properties of polymers according to international standards. We will give you helpful tips on what to consider for the different standards and what is important for reliable test results.
다운로드 위치 Standard-Compliant Measurement of Tensile and Flexural Properties on Plastics
Impact Testing on Polymers - Conventional and Instrumented
Pendulum impact testers determine the impact energy absorbed by a standardized specimen up to break by measuring the height of rise of the pendulum hammer after impact. The result is impact strength or notched impact strength, which is indicated in relation to area, for example in kJ/m². We will give an overview of the standard test methods (Charpy; Izod, Dynstat,…) and explain the difference betw
다운로드 위치 Impact Testing on Polymers - Conventional and Instrumented

복합재

Optical strain measurement for mechanical testing of composites
Non-contact strain measurement has steadily gained importance in the past decades. This presentation will introduce typical composite tests for which optical strain measurement is often used. It introduces the outstanding features of the videoXtens 2-150 HP, including marking free live strain measurement and 2D-DIC.
다운로드 위치 Optical strain measurement for mechanical testing of composites
An Introduction to Composites Testing
Learn about the basics of composites and composites testing or refresh your knowledge. We will show you the basic test methods to enable quality assurance and design of composite structures. Explore how the ZwickRoell portfolio supports static test machines with required equipment, e.g. strain measuring, temperature chambers, or alignment.
다운로드 위치 An Introduction to Composites Testing
An Introduction to Composites Testing
Learn about the basics of composites and composites testing or refresh your knowledge. We will show you the basic test methods to enable quality assurance and design of composite structures. Explore how the ZwickRoell portfolio supports static test machines with required equipment, e.g. strain measuring, temperature chambers, or alignment.
다운로드 위치 An Introduction to Composites Testing
Optical strain measurement for mechanical testing of composites
Non-contact strain measurement has steadily gained importance in the past decades. This presentation will introduce typical composite tests for which optical strain measurement is often used. It introduces the outstanding features of the videoXtens 2-150 HP, including marking free live strain measurement and 2D-DIC.
다운로드 위치 Optical strain measurement for mechanical testing of composites

일반 사항

Modernizing servohydraulic amd dynamic testing machines
You are currently using a servohydraulic / dynamic testing machine from ZwickRoell or from another manufacturer and would now like to work with the latest software and hardware technology with the goal of attaining reliable test results.
다운로드 위치 Modernizing servohydraulic amd dynamic testing machines
Automated Testing Systems with a Smart Robot in an Industry 4.0 Environment
Participants have an overview of which automation solutions are available for metals, plastics, and medical applications. With the help of provided informational material such as a photo library and videos, participants can present and, if necessary clarify the solutions to the customer, while staying within their budget.
다운로드 위치 Automated Testing Systems with a Smart Robot in an Industry 4.0 Environment
Creep testing – Multistation testing for plastics and new creep applications & solutions for metal
Service-life prediction under static and quasi-static long-term loading with the versatile Kappa series creep testing machines for metals, for use with power plant and turbine technology, as well as for light metals, plastics, and composites, for use in lightweight construction and new areas of application.
다운로드 위치 Creep testing – Multistation testing for plastics and new creep applications & solutions for metal
New ZwickRoell hardness testing machines for laboratories and production environments
Introduction and product overview of the new series: DuraScan – state-of-the-art technology, precision and flexibility for laboratory applications; DuraVision – robustness, precision and efficiency for production environments
다운로드 위치 New ZwickRoell hardness testing machines for laboratories and production environments
How do I find the right extensometer for my application
An extensometer has to fulfill many user requirements from the fulfillment of standard requirements up to highest flexibility and automatism. This presentation provides an overview of selection criteria, and shows how you can profit from different extensometer types.
다운로드 위치 How do I find the right extensometer for my application
Simply See More - ZwickRoell 2D DIC
Without the need for additional hardware, the ZwickRoell videoXtens can be expanded with a valuable function: the ZwickRoell 2D DIC. This function allows for live strain measurement with a single extensometer, followed by 2D DIC analysis.
다운로드 위치 Simply See More - ZwickRoell 2D DIC
Maximizing testing machine runtime
You are currently using a ZwickRoell testing machine and want to maximize service life without compromising on modern software, standard compliant testing with the latest technology or operator safety.
다운로드 위치 Maximizing testing machine runtime
How testing can contribute to sustainability in your industry?
Sustainability is one of the megatrends of our time and affects us in all situations. For almost all industries sustainability is becoming a very pressing issue – especially due to uncertain supply chains and the massive increase in the cost of energy and gas as well as the pressure from society.
다운로드 위치 How testing can contribute to sustainability in your industry?
